Engine For Genset
DF Series Engine for Genset
2020/09/03 00:00
| G128 Seies Engine for Genset | ||||
| Engine Model | G128ZLD | G128ZLD2 | G128ZLD1 | G128ZLD11 |
| Type | In-Line、WaterCooled、4-Stroke、Direct injection | |||
| Aspiration | Turbo & Intercooler | |||
| Cylinder No.x Bore x Stroke(mm) | 6x135x150 | |||
| Compression Ratio | 17:1 | |||
| Displacement(L) | 12.88 | |||
| Standby Power(kw) | 206 | 227 | 260 | 308 |
| Rated Speed(r/min) | 1500 | |||
| Min.BSFC(g/kw.h) | 200 | |||
| Oil Consumption(g/kw.h) | 0.6 | |||
| Adjustment rate(%) | 5 | 5(0-5%Adjustable) | ||
| Speed Control Mode | Mechanical | Electronic Speed Control | ||
| Idle Speed(r/min) | 650 | |||
| Noise(db) | ≤115 | |||
| Flywheel & housing | SAE 1# 14# | |||
| Net Weight(kg) | 1200 | |||
| 12V135 Seies Engine for Genset | |||||
| Engine Model | 12V135AZD | 12V135AZLD | 12V135BZLD | 12V135BZLD2 | 12V135BZLD1 |
| Type | V-type、WaterCooled、4-Stroke、Direct injection | ||||
| Aspiration | Turbo | Turbo & Intercooler | |||
| Cylinder No.x Bore x Stroke(mm) | 12x135x150 | 12x135x155 | |||
| Compression Ratio | 16:1 | 16.4:1 | 16:1 | ||
| Displacement(L) | 25.8 | 26.6 | |||
| Standby Power(kw) | 330 | 373 | 445.5 | 505 | 555 |
| Rated Speed(r/min) | 1500 | ||||
| Min.BSFC(g/kw.h) | 210 | 200 | |||
| Oil Consumption(g/kw.h) | 0.7 | ||||
| Adjustment rate(%) | 5 | 5(0-5%Adjustable) | |||
| Speed Control Mode | Mechanical | Electronic Speed Control | |||
| Idle Speed(r/min) | 650 | ||||
| Noise(db) | ≤117 | ||||
| Flywheel & housing | SAE 1/2# 14# | SAE 0# 18# | |||
| Net Weight(kg) | 1850 | 1900 | 1950 | ||
| 12V138 Seies Engine for Genset | ||
| Engine Model | 12V138CZLD | 12V138DZLD |
| Type | V-type、WaterCooled、4-Stroke、Direct injection | |
| Aspiration | Turbo & Intercooler | |
| Cylinder No.x Bore x Stroke(mm) | 12x138x158 | 12x138x168 |
| Displacement(L) | 28.35 | 30.14 |
| Standby Power(kw) | 805 | 880 |
| Rated Speed(r/min) | 1500 | |
| Min.BSFC(g/kw.h) | ≤210 | |
| Oil Consumption(g/kw.h) | 0.7 | |
| Adjustment rate(%) | 5(0-5%Adjustable) | |
| Speed Control Mode | Electronic Speed Control | |
| Idle Speed(r/min) | ≤750±25 | |
| Noise(db) | ≤117 | |
| Flywheel & housing | SAE 0# 18# | |
| Net Weight(kg) | 1950 | |
